Vegetal material

Fresh Tagetes patula L. flowers were collected from plants planted at the The Alsacia, Buenavista, Quindío farm (4° 21’ 35’’ north latitude - 75° 44’ 21’’ west longitude, 1 450 m central mountains), the taxonomic determination was made and a specimen was deposited in the herbarium of the University of Quindio (HUQ) (record # 36926, code # 12929).

Preparation of extracts

The plant material (leaves and flowers) was washed and dried in an oven at 40 °C and then pulverized.

The methanolic extracts of leaves (EMH) and flowers (EMF) dried and pulverized of T. patula, were obtained by continuous percolation with anhydrous methanol for two weeks, the solution was filtered and concentrated using a rotaevaporator (Heydolf brand), finally they were lyophilized until reaching a humidity of approximately 5%.

The chlorophylls of the EMH, were separated by the action of an Ethanol-Water mixture that allows to precipitate them, the obtained solution was filtered under vacuum and concentrated in a rotary evaporator under reduced pressure and at a temperature of 38 °C. This extract was lyophilized until obtaining an extract with approximately 5% humidity.

Phytochemical analysis of T. patula extracts

The EMH and the EMF were evaluated for the identification of tannins, saponins, flavonoids, quinones, sterols, triterpenoids, naphthoquinones and anthraquinones, cardiotonic glycosides, terpene lactones and alkaloids following standard identification methods (^{Carvajal-Rojas et al., 2009}).

DPPH antioxidant activity

The antioxidant activity was determined by the uptake of free radicals of 1,1-diphenyl-2-picrilhydrozyl (DPPH˙) applying the methodology described by ^{Guha et al. (2010} and 2011). Different concentrations of the extracts of T. patula, EM (35, 25, 15, 8, 4, 2 μg mL-1), prepared in methanol, and AE (3, 2.6, 2.1, 1.7, 0.9, 0.65 mg mL-1). The extracts reacted with DPPH for 30 min in the dark, then read at 517 nm in spectrophotometer genesis 5. The calculation of the antioxidant activity was carried out with the formula: antioxidant activity (%)= (control-sample)/(control)*100.

Determination of total phenols

The Folin-Ciocalteu ^{Stagos et al. (2012)} was used to determine the total phenolic content of the extracts, with gallic acid as a standard sample. For each sample 1 mg/ml of each extract was used, all the tests were carried out in triplicate and the results are expressed as mg of gallic acid/g of extract (mg AG g-1).

Obtaining and analysis of the essential oil of T. patula

The extraction of the essential oil (AE) was carried out by steam distillation according to some modifications to the method of Leal and collaborators ^{Torres et al. (2013)}, briefly: 3 kg of leaves and flowers (50:50 of fresh leaves and flowers), were subjected to a steam distillation process (temperature ± 100 °C), to obtain the compounds volatile the condenser was maintained between 0 and 4 °C. The essential oil was separated, by the liquid-liquid extraction method, with ethyl acetate which was removed by rotaevaporation. The essential oil was kept in an amber bottle and in refrigeration, for further analysis.

Determination of essential oil components

It was carried out in a gas chromatograph coupled to a mass spectrometer (CG/EM) zhimadzu, model GC: autosystem. TemXL, MS: turbo plus under the following conditions: Rtx©-5 column of 30 m long, diameter 0.25 μ, injection temperature: 240 °C, injection volume: 5 μL. The detection of the chemical components was by comparison with the mass spectral standards of the respective libraries. The relative percentage of the individual compounds was determined based on the normalization method of the area under the peak using correction factors.

Antibacterial activity

Phytochemical analysis of T. patula extracts

The preliminary phytochemical analysis of the EMH and EMF extracts showed the presence of some secondary metabolites, such as tannins, saponins, flavonoids, terpenes, quinones, sugars and others described in Table 1.

The most abundant compounds for the methanolic extract of leaves were flavonoids, sugars and coumarins, terpene lactones, for the flowers were tannins, flavonoids and sugars.

The secondary metabolites found in this work in the methanolic extracts of leaves and flowers of T. patula, have also been identified by other authors, for example, in this plant, more than twelve flavonoids have been described, such as quercetagestin and its derivatives, kaempferol, kaempferitrin and its derivatives, myricetin and its derivatives, patuletin, and lutein, among others. Also steroids such as β-sitosterol and cholesterol (^{Xu et al., 2012}). Many of these compounds show a high potential to be included as new medicines or as pesticides (^{Raut and Karuppayil, 2014}; ^{Politi et al., 2016}). Also other applications as its antioxidant activity, emerge gradually from the studies of the compounds of Tagetes spp. (^{Raut and Karuppayil, 2014}).

The gas-mass chromatography of the essential oil of leaves and flowers allowed to make a more detailed identification of some of these compounds and their properties as described below.

DPPH antioxidant activity

The EMF had the highest DPPH free radical scavenging capacity, thus: 35 μg mL^-1 EMF, captured 89.52%, 120 μg mL^-1 EMH 85.95% and 3 mg mL^-1 AE (42.41%). The concentration that has 50% uptake of DPPH radicals was established for the EMF at 13.21 μg mL^-1 and for the EMH: 52.85 mg mL^-1: for the essential oil it was not possible to establish it, since its concentration was not comparable with the standard.

Determination of total phenols

The EMF exhibited the highest phenolic content with 227.67 μg Eq- of gallic acid/mg of EMF, followed by EMH with 153.48 μg Eq- of gallic acid/mg of EMH, while the AE of flowers and leaves had the lowest content phenolic with 14.44 g Eq- of gallic acid/mg of AE.

Different works relate the content of phenolic compounds (including flavonoids) in plants with their ability to eliminate free radicals (^{Al Dhaheri et al., 2013}). In this study, a relationship was found between the phenolic content of the extracts and their capacity to capture free radicals, since the extracts with higher phenolic content were found to have a higher DPPH free radical uptake capacity. On the other hand, authors have shown high values of antioxidant activity of the genus Tagetes (^{Kazibwe et al., 2017}).

Furthermore, it has been shown that different allelochemical compounds with potential antioxidant activity are not only involved in the defense mechanisms of the plant, but may be responsible for the cytotoxic activity observed in this genus (^{Politi et al., 2016}); as evidenced by the results against R. solanacearum, which are described below. However, more studies are needed on the cytotoxicity of these compounds and their antioxidant capacity.

Components of T. patula essential oil

Steam distillation of T. patula flowers gave 1 ml kg-1 of essential oil. The qualitative and quantitative analysis of the same, performed by gas-mass chromatography allowed the identification of twenty compounds (Figure 1).

Figure 1 Chromatogram of the essential oil of leaves and flowers of Tagetes patula L.

The major components were six, in ascending order: Indane 5.47%, D-limonene 5.76%, Z-ocimeno 5.98%, terpinolene 6.73%, Bervenona 19.98% and piperitone with 40.4%, representing these six 84.02% of the components identified, which are described in Table 2.

Similar compounds were described by ^{Prakash et al. (2012)}, for the inflorescences of Tagetes patula, they found that the major components of the essential oil of this variety were: 1.8-cineola (4.4%), (Z)-Beta-ocimene (11.8%), terpinolene (6.9%), (Z)-ocimenone (6.4%), (E)-ocimenone (3%), gamma-elemeno (16.9%), piperitenone (3.3%), β-caryophyleno (18.6%) and (E)-β-ionone (2.5%). Very similar to those found in this work, but in lower percentages such as piperitone. Also ^{Kyarimpa et al. (2014)}, in Tagetes minuta essential oil, identified nine major components, three of which coincide with those identified as major in the present work, namely limonene 8%, Beta-trans ocimene 15.9% and verbenone 16.8%.

These differences in components and the relative percentages may be due to environmental and stationary factors related to the cultivation of the plants, to the geographical location, to the part of the plant used, to the species itself (T. patula, T. erecta, T. minuta), to the amount of fresh material, to the extraction systems, although these are very similar and to the amount of irrigation as has been described by ^{Umar et al. (2017)} for T. patula and T. erecta, subjected to different irrigation deficit strategies. They found that components of essential oils such as caryophyllene, terpinolene, and others, can increase in states of stress due to water deficit in different species of Tagetes.

Antibacterial activity

Once obtained the methanolic extracts and the essential oil its antibacterial effect was tested against R. Solanacerum race 2.

Ralstonia solanacearum race 2 (Smith, 1896) is a Gram-negative bacterium in the form of a bacillus that produces Moko disease or bacterial wilt, which affects the vascular system of plants such as banana, banana, tobacco and tomato, among others. The Moko has caused great damage to the cultivars of potatoes, tobacco, bananas and bananas in the world.

Many strategies have been proposed to combat Moko, including cultivating resistant varieties and transgenic plants, or the use of pesticides of natural or chemical origin (^{Ceballos et al., 2014}; ^{Liu et al., 2016}), but all of them with limited success, due to the ability to survive in complex environments, wide range of hosts, wide geographic distribution and genetic diversity of R. solanacearum (^{Ceballos et al., 2014}; ^{Kheirandish and Harighi, 2015}).

The results of the present study show that the EMH does not possess antibacterial activity against R. solanacearum, while the EMF showed a concentration-dependent inhibition, but R. solanacearum race 2, proved to be very sensitive to the AE of T. patula. The diameters for the inhibition zones are shown in Table 3 and Figure 2.

Figure 2 Halves of inhibition of the essential oil (AE) and the methanolic extract of flowers (EMF) against Ralstonia solanacearum race 2.

In this regard, there are several studies that demonstrate the fungicidal, larvicidal and insecticidal capacity of the essential oil of the Tagetes genus (^{Hooks et al., 2010}; ^{Andreotti et al., 2013}; ^{Politi et al., 2016}). Also other studies with extracts from different plants other than the Tagetes genus have shown an antibacterial effect against R. solanacearum, thus Bay et al. (2016), demonstrated that eugenol, a compound of the ethanolic flower extract of Syringa oblata, significantly inhibits the growth of R. solanacearum (18.5 mm inhibition radius). Very similar to the inhibition radius found in our work (diameter 16 mm with the AE). Similarly, Li and collaborators (^{Li et al., 2014}) using Lansiumamide B, which is isolated from Clausena lansium seeds, showed that this compound completely inhibits the growth of R. solanacearum at a concentration of 125 mg/L in vitro. These and other studies show the sensitivity of R. solanacearum to different compounds of plant origin.

In this research and for the first time as far as is known, the antibacterial effect of the methanolic extract of flowers and the essential oil of T. patula against R. solanacearum race 2 is described. T. patula (Asteraceae) is an annual perennial herb belonging to the family of the Asteraceae. Some components of the extracts and the essential oil of T. patula have been previously described (^{Prakash et al., 2012}; ^{Xu et al., 2012}; ^{Politi et al., 2016}), these components are similar to those found in the present. Study as already mentioned. These compounds are biologically active and potentially allelopathic against various pathogens.

Although the role of each of the compounds has not been fully identified, it was observed, for example, that flavonoids and terpenoids have potent anti-bacterial activity, these results show that the methanolic extract of flowers and the essential oil of T. patula , are rich in flavonoids and terpenoids, of the latter the piperitone and verbenone were the most abundant in the essential oil (40.4 and 19.98% respectively), these compounds have been attributed an important antimicrobial activity, specifically bactericidal, thus Brahmi and collaborators found that the main component of the essential oil of Mentha rotundifolia L. was the epoxide of trans-Piperitone (30.2%) and the piperitone oxide (8.7%) and this essential oil achieved the inhibition of the growth of various bacteria (Escherichia coli and Pseudomonas aeruginosa) among others (^{Brahmi et al., 2016}). While ^{Scollard et al. (2016)}, it was found that verbenone inhibits the growth of Listeria monocytogenes.

However, in the present study the effect of these individual compounds was not evaluated, so it can only be suggested that such components or a mixture of them may be responsible for the inhibition capacity of R. solanacearum, indicating the need to continue deepening in the components of the essential oil and its effects on this bacterium.
