Acta botánica mexicana

versão On-line ISSN 2448-7589versão impressa ISSN 0187-7151

Act. Bot. Mex  no.126 Pátzcuaro  2019  Epub 17-Fev-2020

Research articles

Phenotypic traits of Mexican soybean seeds and their correlation with in vitro shoot induction and susceptibility to Agrobacterium infection

Características fenotípicas de semillas de soya mexicana y su correlación con la inducción de brotes in vitro y con la susceptibilidad de infección por Agrobacterium

Soledad Mora Vasquez1  3

Silverio García-Lara1

Guy A. Cardineau1  2

1Tecnológico de Monterrey, Escuela de Ingeniería y Ciencias, Ave. Eugenio Garza Sada 2501, 64849 Monterrey, Nuevo León, México.

2Arizona State University, Beus Center for Law and Society, Mail Code 9520, 111 E. Taylor Street, Phoenix, AZ 85004-4467, USA.


Background and Aims:

Soybean regeneration and transformation are considered highly genotype-specific; however, little is known about desirable seed traits that could be useful indicators of their regeneration and transformation capacities. In the present study, eight commercially available Mexican soybean varieties, as well as the Jack genotype as a control, were phenotypically characterized to determine the seed traits that are important factors for their in vitro performance and susceptibility to Agrobacterium tumefaciens infection.


Grain dimensions, seed weight, moisture, oil, protein, ash, carbohydrate content and macro and micro elements (Mg, K, Ca, P, Na, Mn, Fe, Cu and Zn) were measured and correlated with the corresponding direct shoot organogenesis capability and Agrobacterium infection susceptibility using the cotyledonary node as explant.

Key results:

Notably, the ash content was the only important factor that inversely correlated with the capacity for shoot organogenesis, whereas carbohydrate and phosphorus content were positively correlated with susceptibility to Agrobacterium infection. The best response in terms of multiple shoot formation and Agrobacterium transient transformation was observed with the soybean varieties Huasteca-100, Nainari and Suaqui-86, which have lower ash content and a higher carbohydrate and phosphorus content.


In most reported studies, seed phenotypic traits have been overlooked as factors that influence their regeneration and transformation potential. In the present study, we present evidence of associations between some specific seed traits and regeneration and transient transformation of soybean.

Key words: cotyledonary node; Glycine max; phenotypic characterization; regeneration; soybean genotypes; transient transformation


Antecedentes y Objetivos:

La regeneración y transformación de soya son consideradas altamente genotipo-específicas; sin embargo, muy poco se sabe acerca de rasgos deseables de la semilla que pudieran ser indicadores útiles de sus capacidades de regeneración y transformación. En el presente estudio, ocho variedades de soya mexicanas comercialmente disponibles, así como el genotipo Jack como control, se caracterizaron fenotípicamente con el fin de determinar qué características de la semilla son factores importantes para su desempeño in vitro y su susceptibilidad de infección por Agrobacterium tumefaciens.


Se midieron las dimensiones del grano, el peso de semilla, contenido de humedad, aceite, proteína, cenizas, carbohidratos, así como el contenido de macro y microelementos (Mg, K, Ca, P, Na, Mn, Fe, Cu y Zn) y se correlacionaron con la correspondiente capacidad de organogénesis directa y susceptibilidad de infección por Agrobacterium, usando el nodo cotiledonario como explante.

Resultados clave:

Notablemente, el contenido de cenizas fue el único factor importante que se correlacionó inversamente con la capacidad de organogénesis, mientras que los contenidos de carbohidratos y fósforo se correlacionaron positivamente con la susceptibilidad de infección por Agrobacterium. La mejor respuesta en términos de formación de brotes múltiples y transformación transitoria con Agrobacterium se observó con las variedades de soya Huasteca-100, Nainari y Suaqui-86, las cuales tienen un menor contenido de cenizas y un mayor contenido de carbohidratos y fósforo.


En la gran mayoría de estudios reportados, se han pasado por alto los rasgos fenotípicos de las semillas como posibles factores que influyen en su potencial de regeneración y transformación. En el presente estudio, presentamos evidencia de asociaciones entre algunos rasgos específicos de las semillas con la regeneración y la transformación transitoria de soya.

Palabras clave: caracterización fenotípica; genotipos de soya; Glycine max; nodo cotiledonario; regeneración; transformación transitoria


Soybean (Glycine max (L.) Merr.) is economically the most important legume globally. Besides providing raw materials for the chemical industry, the high lipid and protein content makes it one of the most valuable products for human and animal nutrition (Singh et al., 2008). In Mexico, total soybean production reached 480,000 MT (metric tons) in 2017, while imports were approximately 4,250,000 MT in the same year; national production is forecast to increase slightly in 2018/2019, while consumption and demand for soybean are also expected to increase due to population growth and feed demand from livestock sectors (USDA, 2018).

Genetic transformation of soybean has facilitated the development of new soybean cultivars with higher seed qualities, higher yields and with biotic and abiotic stress tolerances (Tripathi and Khare, 2016). Although soybean genetic transformation and regeneration is routine around the world, the efficiency is often low and the protocols are difficult to reproduce partly because the regeneration capacity and transformation efficiency of soybean are genotype dependent (Zia et al., 2010; Arun et al., 2014). This dependence justifies the screening of soybean varieties that are more suitable for regeneration and Agrobacterium-mediated transformation (Song et al., 2013). It was determined that in China, the most suitable soybean genotype for in vitro regeneration is Hefeng-25 (Ma and Wu, 2008), and in India it is the PK416 cultivar (Arun et al., 2014). However, the seed phenotypic characteristics of the genotypes in question are usually not reported, perhaps because the most common phenotyping techniques are costly, time consuming and destructive to sample (Chen et al., 2014). Consequently, there is a lack of knowledge in terms of desirable phenotypic traits that could contribute to the regeneration and transformation potential. Furthermore, there is a lack of knowledge about Mexican soybean varieties that may be useful for genetic improvement purposes.

Phenotypic characterization of crop seeds is an important tool for plant breeders to identify and improve lineages with better quality (Gupta et al., 2010; Sharma et al., 2016). One tool that has been used, for plant-breeding purposes, to predict crop yield is Near Infrared Reflectance spectroscopy (NIR), which allows a fast, reliable and non-destructive measurement of seed composition (Araus et al., 2001).

We hypothesize that, by using rapid physiology-based screening methods, it is feasible to find a correlation between seed traits and the in vitro performance of soybean. Therefore, the objective of this study is to phenotypically characterize eight Mexican soybean genotypes, and the frequently used soybean line, Jack, as a control, to determine which seed traits are correlated the most with regeneration capability (cotyledonary node approach) and susceptibility to Agrobacterium tumefaciens (Smith & Townsend) Conn infection.

Materials and Methods

Eight Mexican soybean genotypes, described in Table 1, were selected for study based on their commercial availability (Huasteca-100, Huasteca-200, Huasteca-300, Huasteca-400, Huasteca-600, Tamesí, Nainari and Suaqui-86) and were obtained from the INIFAP (Instituto Nacional de Investigaciones Forestales, Agrícolas y Pecuarias, Mexico), while the Jack genotype was kindly provided by the USDA-ARS (United States Department of Agriculture - Agricultural Research Service, USA). The Mexican seeds were harvested in 2013, whereas the Jack cultivar was harvested in 2009. All seeds were stored at 4 ºC until analysis.

Table 1: Description of soybean varieties used in the present study. * (SNICS, 2018) for Mexican genotypes.

Genotype Year of release* Area of adaptability Origin Average yield kg/ha Height (cm) Days to maturity Reference
Huasteca-100 1995 Tropical lowland regions (southern Tamaulipas, eastern San Luis Potosí and northern Veracruz) Cross between Santa Rosa × Jupiter 2387 84 118 -144 (Maldonado Moreno and Ascencio Luciano, 2010a)
Huasteca-200 1995 Tropical lowlands regions with humid and subhumid climate Cross between F81-5344 × Santa Rosa 2160 109 111 -118 (Maldonado Moreno and Ascencio Luciano, 2010b)
Huasteca-300 2004 Tropical lowlands regions with humid and subhumid climate Cross between H82-1930 × H80-2535 2657 78 116 (Maldonado Moreno et al., 2009)
Huasteca-400 2004 Warm humid and subhumid climate Individual selection of Dois Marcos 301 introduced from Brazil 3319 80 111 (Maldonado Moreno et al., 2010)
Huasteca-600 2014 Warm humid and subhumid climate Hybridization between H88-1880 × H88-3668 2988 79 119 (Maldonado Moreno et al., 2017)
Nainari 1997 Northwestern Mexico Suaqui-86 (seed irradiation) 2835 70 120-125 (Cruz Torres, 2008)
Suaqui-86 1987 Northwestern Mexico RadxCajeme × Tetabiate × Cajeme 3456 90 120 (Cortez et al., 2005)
Tamesí 2011 Warm humid and subhumid climate (southern Tamaulipas, eastern San Luis Potosí and northern Veracruz) Cross between Santa Rosa × H80-2535 2602 66 117 (Maldonado Moreno and Ascencio Luciano, 2012)
Jack 1989 Athens, GA; Lexington, KY; and Wooster, OH Fayette × Hardin 3250 100-119 112 (Kaudzu, 2017)

Seed characterization

Soybean seeds were subjected to near infrared spectroscopy (NIR DA7250, Perten Instruments Inc., Springfield, USA) for proximate seed analysis, which includes moisture, oil, protein, ash, and carbohydrate content using a standard sample dish of 108 cm2. Data were calculated on a dry weight basis in triplicate. Grain dimensions (length and width) were measured using a scanner (Epson perfection V700, Nagano, Japan) and the WinSEEDLE image analyzer (Regent Instruments, Inc., Quebec, Canada). Seed weight was calculated as the mean weight of batches of 100 randomly chosen seeds. The regeneration capability was based on the mean number of shoots per explant obtained on Shoot Induction Medium (SIM, see composition below), while susceptibility to Agrobacterium Conn was measured as the mean percentage of area that stained blue per explant in a transient transformation approach using the Gus gene as a reporter of gene expression.

Regeneration and transient transformation

All culture reagents were obtained from PhytoTechnology Laboratories (Shawnee Mission, KS, USA). The basal medium was Murashige and Skoog salts with B5 vitamins, supplemented with 30 g/l Sucrose, and 8 g/l Plant Agar, pH=5.8 (MSB5). The culture room was under a photoperiod of 16 h, a light intensity of 60 µmol/m2 s1 and a temperature of 27-28 ºC.

Sterilized seeds (Olhoft et al., 2006) were soaked in sterile distilled water overnight (13 h) at 27 ºC and germinated during five days on basal medium supplemented with 0.50 mg/l 6-Benzylaminopurine (BAP). The explants (cotyledonary nodes and a portion of hypocotyl) were prepared from the seedlings as described by Ma and Wu (2008). Explants from 5-day-old seedlings were transferred onto a SIM (basal medium and hormones: 3.0 mg/l BAP, 0.2 mg/l Indole-3-butyric acid (IBA), 0.5 mg/l Kinetin (KT)) and incubated for 15 days. After the shoot induction period, the shoots were counted.

The Gus reporter gene, coding for β-glucuronidase , was obtained from the expression vector pBI121 by PCR amplification (primers 5’-CACCATGTTACGTCCTGTAGAAAC-3’ forward and 5’-GATTCATTGTTTGCCTCCCTG-3’ reverse) and subcloned into the pENTR/D-TOPO vector (Invitrogen K240020). The resultant pENTR-GusS vector was recombined into the pB2GW7.0 (VIB-Ghent University, Gent, Belgium) by Gateway cloning (Karimi et al., 2002). The plasmid pB2GW7.0-Gus was transformed into Agrobacterium tumefaciens strain LBA4404. One colony was picked to inoculate 5 ml of liquid LB medium with antibiotics (100 mg/l Spectinomycin and 20 mg/l Rifampicin) and grown overnight (200 rpm, 28 ºC). One day prior to plant transformation, the Agrobacterium overnight culture (one colony in liquid LB with 100 mg/l Spectinomycin and 20 mg/l Rifampicin) was diluted 1/100 in liquid LB medium under the same conditions. When its optical density (OD600) reached 0.8, the culture was centrifuged (5000 G, 5 min) and the pellet re-suspended in liquid co-cultivation medium (SIM without agar, 200 μmol/l acetosyringone, pH 5.5). The explants were prepared from 5-day-old seedlings in the same way as the regeneration protocol described in the preceding section. Explants were inoculated with Agrobacterium for 2 h at room temperature and then transferred to solid co-cultivation medium (SIM supplemented with 1000 mg/l cysteine (Olhoft and Somers, 2001)). After three days of co-cultivation in darkness, the cotyledonary node area was cut and collected for Gus staining. The explants were washed and incubated in Gus histochemical staining solution (GUSS, Sigma-Aldrich) for one day at 37 ºC, after which the explants were maintained in 70% ethanol.

To provide a less subjective measurement of the Gus staining score, the percentage of area that stained blue in each explant was estimated by using a scanner (Epson perfection V700, Nagano, Japan) and the WinSEEDLE image analyzer (Regent Instruments, Inc., Quebec, Canada). Color classifications were created to quantify the blue color area as well as the explant area (mm2) in frontal sections of cotyledonary nodes.

Experimental design and statistics

For regeneration capability and Agrobacterium susceptibility analyses, a completely randomized design was used with nine genotypes and 30 replicates of the entire experiment. The mean number of shoots per explant and the blue staining percentage was recorded. After proving normality assumptions, data was statistically analyzed using ANOVA and the significance of differences among genotypes was contrasted with a Tukey’s test at p<0.05. Analysis of variance and Tukey’s test were also conducted for all the seed phenotypical traits (moisture, protein, oil, ash, total carbohydrate content, as well as length, width, average seed weight) vs. soybean genotypes to determine whether there were significant differences among genotypes. The correlation coefficients (Pearson) between regeneration capability (mean number of shoots per explant), susceptibility to Agrobacterium infection and different seed traits were determined. All statistical analyses were performed using Minitab 17 (Minitab, State College, PA, USA).

Analysis of major and minor nutrients

Weighed soybean flours (0.3 g), and a blank, were digested in a Mars 5 Xtraction CEM microwave oven (Matthews, NC, USA), using 10 ml of concentrated HNO3 with a temperature-time ramp of 18 min from room temperature to 180 ºC, followed by a 10 min hold at this temperature and a maximum power of 800 W. Resulting digests were filtered through Whatman Nº 42 filter paper and diluted to 25 ml in a volumetric flask. Samples were diluted further, 10 and 100 times in 2% HNO3, for minor and major nutrients analysis, respectively. The concentration of elements (Mg, K, Ca, P, Na, Mn, Fe, Cu and Zn) was determined by ICP-MS (Xseries 2 inductively coupled plasma mass spectrometer, Thermo Scientific, Waltham, USA) in the Latin American and Caribbean Water Center facilities. Each sample was measured in triplicate and blank corrected.


Seed Characterization

Table 2 provides protein, oil, ash and total carbohydrate contents (dry basis), as well as length, width and average seed weight, for all Mexican genotypes and the Jack genotype.

Table 2: Phenotypic seed traits of Jack and Mexican soybean seeds. Protein, oil, ash and carbohydrate content are expressed on a dry weight basis. Values represent the mean ± SE of n replicates. a Significance level from ANOVA test (variety vs. trait). H1: Huasteca-100, H2: Huasteca-200, H3: Huasteca-300, H4: Huasteca-400, H6: Huasteca-600, Na: Nainari, Su: Suaqui-86, Ta: Tamesí and Jack. Means that are not connected by the same letters are significantly different according to the Tukey’s test (p<0.05)

Variety Protein % Oil % Ash % Total Carbohydrate % Length mm Width mm Average 100-seed weight g
Jack 42.6±0.8d 23.2±0.1f 6.09±0.06a 28.1±0.8b 6.77±0.06e 6.07±0.04e 14.4±0.3de
H1 45.8±0.1b 24.2±0.1d 5.98±0.03cd 24.0±0.1c 7.12±0.06cd 6.34±0.05cd 14.9±0.2cd
H2 47.6±0.05a 24.6±0.02bc 6.05±0.01abc 21.76±0.01d 7.61±0.06b 6.68±0.05b 16.3±0.3bc
H3 45.8±0.04b 25.6±0.04a 6.08±0.03ab 22.5±0.1d 8.00±0.06a 7.20±0.05a 18.3±0.5a
H4 45.6±0.1b 24.3±0.16cd 6.03±0.02abc 24.1±0.1c 6.88±0.06de 6.05±0.04e 14.3±0.2de
H6 44.9±0.2bc 25.4±0.14a 5.99±0.01bc 23.6±0.1c 7.22±0.07c 6.42±0.05cd 17.0±0.3ab
Na 40.4±0.04e 23.9±0.13e 5.89±0.02de 29.7±0.1a 6.84±0.07de 6.22±0.06de 13.3±0.1ef
Su 42.5±0.2d 22.3±0.02g 5.81±0.01e 29.3±0.2a 6.82±0.07e 6.08±0.07e 12.8±0.3f
Ta 44.6±0.04c 24.9±0.03b 6.04±0.03abc 24.40±0.02c 7.21± 0.07c 6.51±0.06bc 16.7±0.3b
n 3 3 3 3 56 56 3
p valuea <0.001 <0.001 <0.001 <0.001 <0.001 <0.001 <0.001

A significant variation was found for all of the traits among the tested genotypes (p<0.001). The protein content ranged from 40.4-47.6%, the lowest and highest protein contents were registered for Nainari and Huasteca-200, respectively; the oil content ranged from 22.3% (Suaqui-86) to 25.6% (Huasteca-300). The ash content varied from 5.81-6.09%, the minimum ash content were determined for genotypes Suaqui-86 (5.81%) and Nainari (5.89%), while the maximum was shown for Jack (6.09%). The total carbohydrate content ranged from 21.76-29.7%, with lower values of carbohydrate content being registered by Huasteca-200 and Huasteca-300, while higher values were found for Nainari and Suaqui-86. The seed length varied from 6.77-8.00 mm, while the seed width varied from 6.05-7.20 mm, the minimum seed length was registered by the genotype Jack and the maximum by Huasteca-300; the minimum seed width was recorded for Huasteca-400 and the maximum for Huasteca-300. Finally, the 100-seed weight ranged from 12.8-18.3 g, with lower values registered for Suaqui-86 and Nainari and higher values for Huasteca-300 and Huasteca-600.

Regeneration and transient transformation

All evaluated Mexican genotypes produced shoots. According to ANOVA analyses, shoot induction was affected by soybean genotype (p<0.05). Figure 1A shows that higher multiple shoot formation was obtained using varieties Huasteca-100, Nainari and Suaqui-86. Figure 1B illustrates that elongated shoots were able to regenerate directly from the cotyledonary node without an intervening callus phase.

Figure 1: Regeneration capability and Agrobacterium tumefaciens (Smith & Townsend) Conn infection susceptibility in nine soybean genotypes. A. mean number of shoots per explant and blue staining percentage (n=30), error bar with 95% confidence intervals; B. explants with multiple shoots after 15 days in SIM. From left to right: H1: Huasteca-100, H2: Huasteca-200, H3: Huasteca-300, H4: Huasteca-400, H6: Huasteca-600, Na: Nainari, Su: Suaqui-86, Ta: Tamesí and Jack. Means that are not connected by the same letters are significantly different according to the Tukey’s test (p<0.05).

The percentage area of blue stained tissue (Gus assay), as an indication of infection susceptibility (Figs. 1A, 2), also demonstrated significant variation, ranging from 6% in Huasteca-400 to 32% in Jack.

Figure 2: Gus staining assay: A. color classification for the estimation of the blue staining area using image analysis (Winseedle software); B. image of 15 explants (Nainari) showing on average 29% of blue staining.

According to the ANOVA test, the genotype significantly affected infection susceptibility (p<0.001). Mexican varieties such as Huasteca-100, Nainari and Suaqui-86 presented a high staining percentage, comparable to Jack, indicating efficient Agrobacterium early stage infection. With varying degrees, all of the nine tested varieties were susceptible to Agrobacterium-mediated transformation.


According to Table 3, the ash content was the only significant factor (p<0.01) that correlated negatively with the number of shoots per explant; in other words, the higher the ash content the less the regeneration capability.

Table 3: Pearson correlation coefficients between regeneration capability, Agrobacterium tumefaciens (Smith & Townsend) Conn susceptibility and phenotypic traits of Jack and Mexican soybean. *,** Significant at p<0.05 and p<0.01 respectively, n=9.

Length mm Width mm Average 100-seed weight g Protein % Oil % Ash % Total Carbohydrate % Shoots/ explant #
Width mm 0.980**
Average 100-seed weight (g) 0.870** 0.863**
Protein % 0.672 0.529 0.651
Oil % 0.747* 0.744* 0.894** 0.585
Ash % 0.471 0.434 0.675 0.562 0.573
Total Carbohydrate % -0.769* -0.662 -0.812** -0.955** -0.798* -0.644
Regeneration shoots/explant # -0.340 -0.305 -0.593 -0.394 -0.511 -0.896** 0.496
Agrobacterium tumefaciens (Smith & Townsend) Conn infection Blue % -0.576 -0.467 -0.557 -0.730* -0.648 -0.494 0.778* 0.587

The susceptibility of soybean to A. tumefaciens infection correlated directly with carbohydrate content and negatively with protein content.

Aside from the correlations between phenotypic traits and in vitro performance, a direct correlation was observed between oil content and seed weight, a similar correlation has been reported previously (Anwar Malik et al., 2006). We also found a negative correlation between carbohydrate and protein, as well as between carbohydrate and oil content. Other studies have also demonstrated that protein content increases at the expense of total carbohydrates (Wilcox and Shibles, 2001), but contradictory results have been reported by other researchers, who found a positive correlation between total carbohydrates and oil (Li et al., 2012).

Analysis of major and minor nutrients

We performed an analysis of major and minor nutrients (Table 4) that could possibly correlate with ash content and regeneration capability (number of shoots per explant).

Table 4: Major (Mg, K, Ca and P) and minor (Na, Mn, Fe, Cu and Zn) elements in soybean seeds determined by ICP-MS. Values represent the mean ± SE of three replicates. aSignificance level from ANOVA test (variety vs. element). Means that are not connected by the same letters are significantly different according to the Tukey’s test (p<0.05).

Soybean Variety 24Mg mg/g 39K mg/g 44Ca mg/g 31P mg/g 23Na mg/kg 55Mn mg/kg 56Fe mg/kg 65Cu mg/kg 66Zn mg/kg
Jack 6.19±0.09a 44.3±0.7ab 3.81±0.06a 5.28±0.18b 432.1±10.1a 65.7±0.3d 167±2b 23.5±0.1d 97.3±1.0c
H1 4.27±0.12d 36.8±0.9d 2.27±0.09e 3.97±0.16c 46.1±4.1f 48.4±1.0e 88±2e 22.7±0.4d 86.3±2.1de
H2 4.93±0.05c 41.3±0.2c 2.23±0.02e 3.21±0.10d 45.7±1.4f 47.8±0.4e 107±5de 26.5±0.7c 82.3±1.5e
H3 5.09±0.02c 41.1±0.2c 2.82±0.03c 3.43±0.02cd 68.2±1.9de 69.3±1.0c 98±4e 19.5±0.4e 82.8±1.5de
H4 4.62±0.07d 42.4±0.2bc 2.26±0.04e 3.66±0.07cd 113.2±4.5b 74.4±1.0b 141±4bc 23.1±0.4d 87.2±2.0de
H6 5.08±0.02c 43.9±0.2ab 2.85±0.01c 3.71±0.03cd 96.8±1.0b 65.9±0.3cd 127±2cd 22.2±0.2de 90.6±0.3cd
Na 5.57±0.03b 44.6±0.2ab 3.09±0.02b 5.93±0.15a 58.8±0.5ef 78.0±0.4a 211±13a 29.9±1.3b 116.7±1.1b
Su 5.83±0.10b 45.8±0.5a 2.58±0.04d 6.03±0.25ab 104.9±4.0b 75.2±0.7ab 225±5a 43.1±0.4a 136.2±2.7a
Ta 4.95±0.06c 41.1±0.4c 2.73±0.03cd 3.30±0.06d 80.9±3.7c 67.1± 0.9cd 108±4de 22.4±0.3d 82.6±1.3de
p valuea <0.001 <0.001 <0.001 <0.001 <0.001 <0.001 <0.001 <0.001 <0.001

In the same manner, the elements were tested for correlation with susceptibility to A. tumefaciens infection. Table 4 shows that mineral content variation was significant among soybean genotypes. From lowest to highest, the following was determined: Mg content ranged from 4.27 mg/g in Huasteca-100 to 6.19 mg/g in Jack; K from 36.8 mg/g in Huasteca-100 to 45.8 mg/g in Suaqui-86; Ca from 2.23 mg/g in Huasteca-200 to 3.81 mg/g in Jack; and P from 3.21 mg/g in Huasteca-200 to 6.03 mg/g in Suaqui-86. In a similar manner, with respect to concentration of micronutrients, the following was determined: Na ranged from 46.1 mg/kg in Huasteca-100 to 432.1 mg/kg in Jack; Mn ranged from 48.4 mg/kg in Huasteca-100 to 78 mg/kg in Nainari; Fe from 88 mg/kg in Huasteca-100 to 225 mg/kg in Suaqui-86; Cu from 19.5 mg/kg in Huasteca-300 to 43.1 mg/kg in Suaqui-86; and Zn ranged from 82.3 mg/kg in Huasteca-200 to 136.2 mg/kg in Suaqui-86.

Table 5 illustrates that the ash content (determined by NIR) had a significant correlation with Na and Ca; both minerals negatively affected regeneration under the present protocol conditions.

Table 5: Pearson correlation coefficients between ash content (NIR), regeneration capability, Agrobacterium tumefaciens (Smith & Townsend) Conn susceptibility and elements measured by ICP-MS. *,** Significant at p<0.05 and p<0.01 respectively. N=9.

Mg K Ca P Na Mn Fe Cu Zn
Ash content % 0.544 0.220 0.770* -0.010 0.871** 0.029 -0.052 -0.354 -0.238
Regeneration Shoots/ explant # -0.037 -0.048 -0.272 0.534 -0.435 -0.075 0.399 0.597 0.590
Agrobacterium tumefaciens (Smith & Townsend) Conn infection Blue % 0.596 0.241 0.558 0.760* 0.389 0.111 0.535 0.442 0.616

However, this interaction was not significant. Additionally, we did not find any significant correlation between specific minerals and regeneration capability. Regarding susceptibility to Agrobacterium infection, P was the only element that correlated significantly with the percentage area of blue staining.


Under these protocol conditions, Mexican varieties such as Huasteca-100, Nainari and Suaqui-86 had a better regeneration capacity than Jack in terms of the number of shoots produced from one explant. In previous studies, Jack has been found to induce highly embryogenic responses (Lee et al., 2013), which makes it optimal for somatic embryogenesis regeneration approaches. However, our results have shown that the Jack genotype was not highly proliferative in a direct regeneration approach using the cotyledonary node as explant, which is in agreement with recently reported results (Raza et al., 2017).

Three Mexican varieties were the most regenerative. With regard to Huasteca-100, it is a genotype developed from the hybridization of a Brazilian genotype (Santa Rosa) and an American genotype (Jupiter); it is adapted to tropical Mexican areas (Maldonado Moreno and Ascencio Luciano, 2010a). Nainari (also known as Hector) was developed by seed irradiation of Suaqui-86 (Cruz Torres, 2008), and hence both are closely related and both are adapted to northwestern Mexico. The eight Mexican genotypes analyzed in this study were adapted for different agroclimatic zones and, as such, it was expected to observe phenotypic differences among them (Vasconcelos et al., 2006). We showed that different genotypes exhibited significant differences in composition within already reported ranges (Bellaloui et al., 2011), as well as significant differences in size and dimensions. Among all observed genotypic differences between seed traits, regeneration capability and susceptibility to infection, ash content had a significant negative correlation with regeneration capability, whereas carbohydrate content presented the most significant correlation with susceptibility to Agrobacterium infection. These results suggest that ash content may be an indicator of soybean regeneration capability, with carbohydrate content being indicative of infection susceptibility using the current protocol.

Specific phenotypic seed traits have been reported and associated with field performance (Walter et al., 2015). A negative correlation between ash content and grain yield exists in several cereals under specific environmental conditions (Misra et al., 2006). Although the underlying mechanism remains unclear, the accumulation of minerals in mature seeds has been considered a complimentary criterion to evaluate water use efficiency and to predict yield in C3 and C4 plants (Cabrera-Bosquet et al., 2011). In a similar way, seed ash content could be an indicator of water-use efficiency in a regeneration process; however, there is scarce information in the literature on this relationship in in vitro settings.

Considering that ash content was an important factor that could affect regeneration, we performed an analysis of major and minor nutrients. Our findings show that two specific elements: Ca (a major element) and Na (a trace element) correlated the most with ash content values (NIR). However, we did not find any significant correlation between regeneration and any specific element, suggesting that regeneration was perhaps affected either by the combination of two or more elements present in the ash or by additional elements that were not quantified in this study. Although the correlation between regeneration capability and these two elements (Ca and Na) was not significant, it was an inverse relationship, meaning that higher amounts of calcium and sodium accumulated in the seeds could have a detrimental effect on soybean in vitro performance. In contrast, the macroelement P and the microelements Fe, Zn and Cu showed a positive (but not significant) correlation with regeneration capacity. Phosphorus (P) plays essential roles in metabolic pathways and is a key component of molecules such as ATP, nucleic acids and phospholipids (Schachtman et al., 1998); Fe is essential mainly in the metabolism of chlorophylls and its deficiency induces chlorosis, while Zn is also essential because it is a co-factor in a large number of enzymes and its deficiency inhibits cell growth (Ghasemian et al., 2010). Cu is also important for plant growth and development since it can act as co-factor in many enzymes and has a role in transcription-signaling pathways and protein trafficking (Yruela, 2005).

The susceptibility to Agrobacterium infection correlated with phosphorus, carbohydrate content and, to a lesser degree, inversely with protein content. Phosphorus is an essential nutrient which plays a well-documented role in synthetic, developmental and signaling pathways important to plant function (Raboy, 2009), but such effects in the Agrobacterium transient transformation of soybean have not been reported. Carbohydrates may correlate with susceptibility to Agrobacterium infection due to a higher concentration of monosaccharides being released from plant wounds; monosaccharides, in combination with phenolic compounds, are required for transcriptional activation of the Agrobacterium transformation system (Tzfira and Citovsky, 2002). Genotypes with higher carbohydrate content have naturally less protein content, hence the negative correlation found between protein and Agrobacterium infection.

In most cases, seed phenotypic traits have been overlooked, at least in relation to regeneration and transformation potential. However, we present here evidence of associations between specific seed traits with soybean regeneration and transient transformation. More research in this area would lead to a better understanding of important factors that affect these two processes under determined conditions. The seed characterization can be easily performed with non-invasive and reliable methods such as those presented in this work (Ferreira et al., 2014).

In conclusion, three Mexican soybean varieties, Huasteca-100, Nainari and Suaqui-86, were the most suitable for in vitro regeneration through a cotyledonary node explant; all three varieties were also found to be highly susceptible to gene transfer by Agrobacterium in a transient transformation approach. After characterizing eight Mexican varieties, and the Jack genotype as a control, it was possible to determine an inverse correlation between ash content and regeneration capability and a direct correlation between carbohydrate and phosphorus content and susceptibility to Agrobacterium infection. According to the reviewed literature in that regard, this is the first reported study performed on these Mexican genotypes and the first to use NIR as a screening tool to correlate phenotypic traits with soybean in vitro performance. This study will be advantageous for future soybean genetic improvement and transformation research.

Author contributions

SMV performed the experiments and wrote the paper, SGL and GAC contributed with data analysis and improvement of the manuscript.


We thank Sergio Serna and Robert Winkler for manuscript review before submission to the journal. Special thanks are expressed by the principal author to Julio Rivera, Karla Lorena López and Francisco Almeida for their technical assistance.

Literature cited

Anwar Malik, M. F., A. Qureshi, M. Ashraf and A. Ghafoor. 2006. Genetic Variability of the Main Yield Related Characters in Soybean. International Journal of Agriculture and Biology 8: 815-819. [ Links ]

Araus, J. L., J. Casadesus and J. Bort. 2001. Recent tools for the screening of physiological traits determining yield. In: Reynolds, M. P., J. I. Ortiz-Monasterio and A. McNab (eds.). Application of Physiology in Wheat Breeding. International Maize and Wheat Improvement Centrer (CYMMIT). Mexico, D.F., Mexico. Pp. 59-77. [ Links ]

Arun, M., K. Subramanyam, J. Theboral, A. Ganapathi and M. Manickavasagam. 2014. Optimized shoot regeneration for Indian soybean: the influence of exogenous polyamines. Plant Cell, Tissue and Organ Culture 117(2): 305-309. DOI: [ Links ]

Bellaloui, N., K. N. Reddy, H. A. Bruns, A. M. Gillen, A. Mengistu, L. H. S. Zobiole, D. K. Fisher, H. K. Abbas, R. M. Zablotowicz and R. J. Kremer. 2011. Soybean seed composition and quality: Interactions of environment, genotype, and management practices. In: Maxwell, J. E. (ed.). Soybeans: Cultivation, Uses and Nutrition. Nova Science Publishers, Inc. New York, USA. Pp. 1-42. [ Links ]

Cabrera-Bosquet, L., C. Sánchez, A. Rosales, N. Palacios-Rojas and J. L. Araus. 2011. Near-Infrared Reflectance Spectroscopy (NIRS) assessment of δ18O and nitrogen and ash contents for improved yield potential and drought adaptation in maize. Journal of Agricultural and Food Chemistry 59(2): 467-474. DOI: [ Links ]

Chen, D., K. Neumann, S. Friedel, B. Kilian, M. Chen, T. Altmann and C. Klukas. 2014. Dissecting the Phenotypic Components of Crop Plant Growth and Drought Responses Based on High-Throughput Image Analysis. The Plant Cell 26(2): 4636-4655. DOI: [ Links ]

Cortez, E., Rodriguez, J. L. Martínez and J. Macías. 2005. Tecnología de Producción y Manejo de la Mosca Blanca de la Hoja Plateada en el Cultivo de Soya en el Norte de Sinaloa. Instituto Nacional de Investigaciones Forestales, Agrícolas y Pecuarias - Centro de Investigación Regional del Noroeste Campo Experimental Valle del Fuerte. Folleto técnico Núm. 25. Los Mochis, Sinaloa, México. 52 pp. [ Links ]

Cruz Torres, E. 2008. The role of mutation breeding on plant improvement in Mexico. In: The Food and Agriculture Organization - International Atomic Energy Agency Division of Nuclear Techniques in Food and Agriculture (ed.). International Symposium on Induced Mutations in Plants (ISIM). International Atomic Energy Agency (IAEA). Vienna, Austria. Pp. 12-15. [ Links ]

Ferreira, D. S., O. F. Galão, J. A. L. Pallone and R. J. Poppi. 2014. Comparison and application of near-infrared (NIR) and mid-infrared (MIR) spectroscopy for determination of quality parameters in soybean samples. Food Control 35(1): 227-232. DOI: [ Links ]

Ghasemian, V., A. Ghalavand, A. Soroosh Zadeh and A. Pirzad. 2010. The effect of Iron, Zinc and Manganese on quality of soybean seed. Journal of Phytology 2(11): 73-79. [ Links ]

Gupta, P., R. Singh, S. Malhotra, K. S. Boora and H. R. Singal. 2010. Characterization of seed storage proteins in high protein genotypes of cowpea (Vigna unguiculata (L.) Walp.). Physiology and Molecular Biology of Plants 16(1): 53-8. DOI: [ Links ]

Karimi, M., D. Inzé and A. Depicker. 2002. GATEWAY™ vectors for Agrobacterium-mediated plant transformation. Trends in Plant Science 7(5): 193-195. DOI: [ Links ]

Kaudzu, G. 2017. Soybean (Glycine max (L.) Merr.) agronomic performance, seed characteristics and aconitase isozymes variability in response to environmental stimuli. Graduate Theses and Dissertations. Iowa State University. Iowa, USA. Pp. 41-75. DOI: [ Links ]

Lee, H., S. Park and Z. J. Zhang. 2013. An Overview of Genetic Transformation of Soybean. In: Board, J. E. (ed.). A Comprehensive Survey of International Soybean Research. IntechOpen. London, UK. Pp. 489-506. DOI: [ Links ]

Li, Y., M. Du, Q. Zhang, G. Wang, M. Hashemi and X. Liu. 2012. Greater differences exist in seed protein, oil, total soluble sugar and sucrose content of vegetable soybean genotypes (Glycine max (L.) Merr.) in Northeast China. Australian Journal of Crop Science 6(12): 1681-1686. DOI: [ Links ]

Ma, X. H. and T. L. Wu. 2008. Rapid and efficient regeneration in soybean (Glycine max (L.) Merr.) from whole cotyledonary node explants. Acta Physiologiae Plantarum 30(2): 209-216. DOI: [ Links ]

Maldonado Moreno, N. and G. Ascencio Luciano. 2010a. Huasteca 100, variedad de soya para el Sur de Tamaulipas y trópico de México. Revista Mexicana de Ciencias Agrícolas 1(5): 699-705. [ Links ]

Maldonado Moreno, N. and G. Ascencio Luciano. 2010b. Huasteca 200, variedad de soya de baja sensibilidad al fotoperiodo corto para el trópico de México. Revista Mexicana de Ciencias Agrícolas 1(5): 707-714 [ Links ]

Maldonado Moreno, N. and G. Ascencio Luciano. 2012. Tamesí, nueva variedad de soya para el trópico húmedo de México. Revista Mexicana de Ciencias Agrícolas 3(8): 1671-1677. DOI: [ Links ]

Maldonado Moreno, N., G. Ascencio Luciano and H. R. Gill-Langarica. 2009. Huasteca 300, Nueva variedad de soya para el sur de Tamaulipas. Agricultura Técnica en México 35(4): 481-485. [ Links ]

Maldonado Moreno, N., G. Ascencio Luciano and H. R. Gill-Langarica. 2010. Huasteca 400, Nueva variedad de soya para el sur de Tamaulipas, oriente de San Luis Potosí y Norte de Veracruz. Revista Mexicana de Ciencias Agrícolas 1(5): 687-692. [ Links ]

Maldonado Moreno, N., G. Ascencio Luciano and J. C. García Rodríguez. 2017. Huasteca 600, variedad de soya para el sur de Tamaulipas. Revista Mexicana de Ciencias Agrícolas 8(8): 1897-1904. [ Links ]

Misra, S. C., R. Randive, V. S. Rao, M. S. Sheshshayee, R. Serraj and P. Monneveux. 2006. Relationship between carbon isotope discrimination, ash content and grain yield in wheat in the Peninsular Zone of India. Journal of Agronomy and Crop Science 192(5): 352-362. DOI: [ Links ]

Olhoft, P. M., C. M. Donovan and D. A. Somers. 2006. Soybean (Glycine max) transformation using mature cotyledonary node explants. In: Wang, K. (ed.). Agrobacterium Protocols. Methods in Molecular Biology vol. 343. Humana Press. Totowa, USA. Pp. 385-396. DOI: [ Links ]

Olhoft, P. M. and D. A. Somers. 2001. L-Cysteine increases Agrobacterium-mediated T-DNA delivery into soybean cotyledonary-node cells. Plant Cell Reports 20(8): 706-711. DOI: [ Links ]

Raboy, V. 2009. Approaches and challenges to engineering seed phytate and total phosphorus. Plant Science 177(8): 281-296. DOI: [ Links ]

Raza, G., M. B. Singh and P. L. Bhalla. 2017. In Vitro Plant Regeneration from Commercial Cultivars of Soybean. BioMed Research International 7379693: 1-9. DOI: [ Links ]

Schachtman, D. P., R. J. Reid and S. M. Ayling.1998. Phosphorus Uptake by Plants: From Soil to Cell. Plant Physiology 116: 447-453. DOI: [ Links ]

Sharma, S. S., M. A. Islam, A. A. Malik, K. Kumar, M. S. Negi and S. B. Tripathi. 2016. Seed traits, fatty acid profile and genetic diversity assessment in Pongamia pinnata (L.) Pierre germplasm. Physiology and Molecular Biology of Plants 22(2): 193-205. DOI: [ Links ]

Singh, P., R. Kumar, S. N. Sabapathy and A. S. Bawa. 2008. Functional and edible uses of soy protein products. Comprehensive Reviews in Food Science and Food Safety 7(1): 14-28. DOI: [ Links ]

SNICS. 2018. Catálogo Nacional de Variedades Vegetales. Secretaría del Medio Ambiente, Recursos Naturales y Pesca (SEMARNAT). Cd. Mx, México. 38 pp. ]

Song, Z., J. Tian, W. Fu, L. Li, L. Lu, L. Zhou, Z. Shan, G. Tang and H. Shou. 2013. Screening Chinese soybean genotypes for Agrobacterium-mediated genetic transformation suitability. Journal of Zhejiang University, Science B 14(4): 289-298. DOI: [ Links ]

Tripathi, N. and D. Khare. 2016. Molecular approaches for genetic improvement of seed quality and characterization of genetic diversity in soybean: a critical review. Biotechnology Letters 38(10): 1645-1654. DOI: [ Links ]

Tzfira, T. and V. Citovsky. 2002. Partners-in-infection: Host proteins involved in the transformation of plant cells by Agrobacterium. Trends in Cell Biology 12(3): 121-129. DOI: [ Links ]

USDA. 2018. MX8013 2018 Oilseeds and Products Annual Report. (consulted August, 2018) [ Links ]

Vasconcelos, I. M., C. C. Campello, J. T. A. Oliveira, A. Urano, D. Bezerra de Souza and F. Maia. 2006. Brazilian soybean Glycine max (L.) Merr. cultivars adapted to low latitude regions : seed composition and content of bioactive proteins. Brazilian Journal of Botany 29(4): 617-625. DOI: [ Links ]

Walter, A., F. Liebisch and A. Hund. 2015. Plant phenotyping: from bean weighing to image analysis. Plant Methods 11: 1-14. DOI: [ Links ]

Wilcox, J. R. and R. M. Shibles. 2001. Interrelationships among seed quality attributes in soybean. Crop Science 41(1): 11-14. DOI: [ Links ]

Yruela, I. 2005. Copper in plants. Brazilian Journal of Plant Physiology 17(1): 145-156. DOI: [ Links ]

Zia, M., Z. Rizvi, R. U. Rehman and M. Chaudhary. 2010. Agrobacterium mediated transformation of soybean (Glycine max L.): some conditions standardization. Pakistan Journal of Botany 42(4): 2269-2279. [ Links ]

To cite as:

Mora Vasquez, S., S. García-Lara and G. A. Cardineau. 2018(2019). Phenotypic traits of Mexican soybean seeds and their correlation with in vitro shoot induction and susceptibility to Agrobacterium infection. Acta Botanica Mexicana 126: e1421. DOI: 10.21829/abm126.2019.1421


This study was supported by the Tecnológico de Monterrey through CIDPRO (Centro de Investigación y Desarrollo de Proteínas), Centro de Agrobiotecnología, and Centro de Biotecnología, and by the Consejo Nacional de Ciencia y Tecnología (CONACyT) which granted a scholarship to SMV (reference 487097/277870).

Received: July 09, 2018; Revised: October 10, 2018; Accepted: September 03, 2018

3Author for correspondence:

Creative Commons License This is an open-access article distributed under the terms of the Creative Commons Attribution License
